Turn on the music!
Close your eyes ...
Enjoy the illusion of being at the concert ...
Loudspeakers and listening room are forgotten!
Hear stereo at its best!
2015 - The LX family of active and DSP
controlled loudspeakers for superb sound in a wide range of applications and
- A 2-way loudspeaker that can
be built for around $1000 including miniDSP 2x4 equalizer/crossover and 4 power
amplifiers in the 50 W to 200 W range. The speaker has a unique polar pattern,
starting out as omni at low frequencies from the infinite transmission line
woofer, going through a cardioid region around the 800 Hz crossover to an
unbaffled, fullrange driver with dipolar behavior. Due
to the low crossover frequency and acoustically close proximity of drivers the
polar pattern is identical in vertical and horizontal directions, like in a
coaxial design, but it has much wider dispersion at higher frequencies. The
frequency range extends from 45 Hz to 20 kHz with 12 dB/octave roll-off at the
LXmini Construction Plans: $105
LXstudio - A 3-way loudspeaker that combines the
LXmini with the dipole woofers of the LX521. It requires addition of two 200 W
or four 50 W power amplifiers and a miniDSP 4x10HD unit to form a system that
covers the 20 Hz to 20 kHz frequency range with excellent clarity and dynamism.
With an LR2 crossover at a low 60 Hz the woofers can be placed against the side
walls of a room and the LXmini used as near-field monitors. Path length
differences to the listener can be compensated for in the DSP unit. Dipole
woofers have the advantage of less room mode excitation, which matters even in a
highly damped recording/mixing studio. (The design is in the final evaluation
LXmini Construction Plans: $105 + LXstudio Supplemental
LX521.4 - A 4-way loudspeaker, designed as
full-range dipole, for flat on-axis and off-axis response in the horizontal
plane and frontal hemisphere. It requires between 8 to10 power amplifiers of 50
W to 200 W and a miniDSP 4x10HD. The speakers need breathing room of at least 1
m to the nearest large reflecting surfaces and a room with a minimum floor size
of 25 sqm. (The design is in the final evaluation phase.)
LX521 Construction Plans: $155 (LX521.4
addition available to all plan owners late May without cost)
I consider each one of the three systems as
state-of-the-art for rendering a convincing stereo illusion, that touches one's
emotions, that is analytically revealing of flaws in the recording, yet at the
same time forgiving them, if the art comes through. I therefore recommend
building these speakers not only to the DIY community, but also to professional
recording/mixing/mastering engineers and especially to the designers of consumer
products to hear for themselves what they have been missing. Hopefully these
designs inspire a fresh look at what is possible in terms of believable 3D from
two speakers before everyone launches off into 3D over
headphones with their unnatural distance distortion.
For further details about these speaker
systems, about ordering plans, construction materials, miniDSP and amplifiers,
start with the LXmini, LXstudio or LX521
2014 and earlier
15 Years of
Reference Quality Sound in any size room
The LX521 loudspeakers are no longer alone in
their ability to render in stereo a detailed 3D auditory scene with
clarity, dynamism and neutral timbre for any kind of music.
The LXmini, at smaller size and lower cost, is a
close match to its bigger brother, except for lower maximum sound
capability below 200 Hz and rolling off the bass below 45 Hz. While the
LX521 needs at least a 25 m2 room and open space around it,
the LXmini was designed to work well in any size room. The standard
stereo triangle formed by loudspeakers and listener can be as small as 1
m for each side and be close to a wall. But unlike with headphones the
auditory illusion is in front and stays there with head movement as is
natural. Of course the size and distance to the auditory illusion
increases with spreading out the triangle, limited only by the space
The LXmini is easy to build. No soldering is
required, just sawing, sanding, drilling holes, screwing parts together
and crimping wire connections.
is in reach of every music lover!
LX521 - Reference Loudspeaker
Few people have ever heard the detailed 3D
rendering and realism that the stereo format is capable of when the
loudspeakers are designed to illuminate the room evenly for all sounds
and are properly set up in the room.
The LX521 Reference Loudspeaker is an open-baffle,
constant directivity radiator for the enjoyment of any type of music in
the home and also for final judgment of work in the recording studio.
The LX521 is designed to minimize the
influence of the listening room upon the stereo image, which is formed in
the listener's mind. The loudspeakers
themselves disappear from aural perception, leaving in front of you a
phantom acoustic scene to enjoy and study, and not just from the
"sweet spot". Ultimately you are likely to get
lost in the music. That is what I experience with a good recording.
Most of my involvement with audio was about
designing and building loudspeakers for my own use, for my own home. I
have tried to push the state of the art, because I was never quite
satisfied with commercial products, or could not afford what I liked at
the time. I also discovered that even the best professional loudspeaker
designers had unanswered questions and that I was not alone in my search. My
education in electrical engineering, my work in electronic test
equipment design and in microwaves had given me a good opening for
designing broadband acoustic radiators that cover a range of
wavelengths, which is equivalent to the range from 20 MHz to
20 GHz in electromagnetic terms.
I have developed a deep appreciation of
how the brain constructs an aural scene from the multiplicity of
superimposed sound streams, which impinge upon each eardrum all the
time. The brain's working suggests how to design a loudspeaker so that
it can withdraw attention from the loudspeaker as the source of sound
and the listening room as the real place, thus leaving an aural scene, an
illusion floating in front of the listener.
as close to Live -
as the Recording provides!
MAGIC is my other name
for the LX521.
My search is over!
In 2002 I put out the challenge
to build yourself a high performance open-baffle loudspeaker system with
electronic crossover/equalizer and multiple power amplifiers. The ORION
incorporated what I had learned from designing loudspeakers for Audio Artistry
and the follow-on PHOENIX. Soon after, Don Naples from Wood Artistry joined to
supply precut wood parts and then complete, custom finished ORION systems. Today
you can find hundreds of delighted ORION owners all over the world.
The loudspeaker's design changed somewhat over
the years. The midrange driver was mounted by its magnet. A rear tweeter was
added. The frequency response was tweaked after hearing the first PLUTO. Don
Barringer, a trained musician and former recording engineer with the US Marine
Band, helped me in this process with many hours of listening. I am not touching
the design anymore. The ORION has reached its full potential.
ORION with optional THOR subwoofers in back
PLUTO came about
in 2005 after I had used its AURA tweeter as a small loudspeaker for low
frequency room mode studies in a 10:1 scale model of my listening room. The
tweeter opened the possibility of building a fairly decent omni-directional
loudspeaker. I needed it as a reference source for studying baffle diffraction
effects of the ORION.
PLUTO evolved to the 2-way full-range loudspeaker that it
is today when SEAS supplied me with a custom woofer/midrange driver. The
loudspeaker is now ideally suited for smaller living spaces or as a lower cost
alternative to ORION in larger rooms. PLUTO delivers great sound to hundreds of
audiophiles worldwide, following ORION's example.
PLUTO-2.1 is a great father-son/daughter DIY
project. The speaker has built-in power amplifiers, hooks up to the iPod or laptop
and is easily moved. It provides an introduction to high quality sound.
I launched this website in 1999 after I had
separated from Audio Artistry. I left behind three proud design
accomplishments: Vivaldi, Dvorak and Beethoven, all open-baffle loudspeakers.
Much had been learned about loudspeaker design with passive and active
crossover/equalizers. It added
to what I had gathered from my audio hobby activities with other
engineers at Hewlett-Packard Co. Especially Russ Riley, Lyman Miller and
Brian Elliott had inspired me. So on leaving AA I wanted to write it all down,
that it might benefit others and not get lost.
The PHOENIX project
was meant to be an illustrative exercise for others to judge the
validity of what I was claiming. A study of the material will give you useful
insight into the theory, design and construction
of an open-baffle speaker, the necessary line-level crossover/equalizer and
For the later ORION design I combined the
separate dipole woofer with midrange and tweeter in a single cabinet. I also avoided
the MTM driver arrangement.
PHOENIX main panel and
separate dipole woofer in W-frame
If you want to learn about the theory behind
stereo, about what it takes to create a phantom acoustic scene between two
loudspeakers in your living room, then read Stereo
Recording and Rendering - 101.
Publications, Talks, Links, CD's
To get a taste of the large number of considerations that enter into the design
of a loudspeaker you might read a ground breaking "Loudspeaker System Design"
article. It was published 1978 in Wireless World magazine and describes a three-enclosure loudspeaker with
active delay and crossovers using drivers that were highly regarded at the
time, KEF T27, B110 and B139.
And then listen
to a talk given 30 years later about accurate sound reproduction from
two loudspeakers in a living room, to hear and see what more has been learned.
Or see my take on loudspeakers in
On the Links and Other designs pages you will
find relevant and interesting material. It will show you that there is
still much to learn about the optimum configuration of loudspeaker, room,
recording in order to create a "realistic sound illusion".
I offer recordings of useful test signals for room analysis and sound tracks to evaluate your
Look at the Site map to
orient yourself when searching for specific information.
Check out the ORION/PLUTO/LX521
User Group for the exchange of ideas, for questions about LX521, ORION and PLUTO and to make
contact with owners.
You have come to a website with a wealth of
useful and practical information about loudspeaker design, electro-acoustic system
design and about perception of sound from loudspeakers in normal rooms. I have been active in
this field for over 40 years, motivated by my love for music and by a keen
interest in the difficulties of reproducing music realistically in the home.
After retiring from Hewlett-Packard Co. (now 'Agilent') with 37
years in R&D of radio-frequency and microwave electronic test equipment, I
pursued my investigation of the loudspeaker-room-listener interaction with refreshed
energy and time. In
the late nineties I had developed the Beethoven/Dvorak/Vivaldi line of open-baffle
loudspeakers for Audio Artistry. My objective has always been the development of
cost effective loudspeaker systems for two-channel sound
playback of the highest accuracy. Occasionally I experiment with surround
sound. Video sound and moving pictures are of low interest to me, but digital
photography has rekindled my lifelong fascination with pictorial expression.
On this site you will find the essence of what I have
learned from designing, building and listening to many different types of speakers.
was rarely bound by commercial considerations or restricted by market
expectations. I was free to search for the
parameters that are truly important to realistic reproduction. Throughout this
search, my sonic reference
has always been the
non-amplified original performance.
My motto has always been to be "true to the
original, as it was recorded". I want to reproduce a recording without
adding or subtracting from it either because of the loudspeakers or the room.
The recording then defines the possible realism of the auditory scene. On this website you
information that allows you to build, to purchase, or to design loudspeakers which
exemplify the pursuit of realistic rendering.
Check out the topics that are listed in the
column on the left hand side of this page. I hope that the material presented here will add to
your understanding of what is necessary for accurate sound reproduction.
Regrettably, much misinformation and outright nonsense has been published to promote
certain "high-end" audio
products. The power of suggestion works exceedingly well,
listeners do not trust their own hearing. I recommend to re-calibrate yourself frequently.
Listen closely to all sorts of non-amplified sounds in order to
recognize and remember natural sonic scenes. Without a reality based
mental reference it becomes an endless and futile pursuit to listen for differences between
speakers and equipment in order to find the least falsification and a believable
illusion of live sound and space.
The content of any page may change without notice
as I learn new things or find better descriptions. The designs presented here
may change as I make new observations or gain more insight. Audio has overwhelmingly been a hobby for me, for my own pleasure and love of
music. I enjoy to share what I found and possibly to dispel a few
misconceptions. My interest is not on the business side, though I like that my
activities pay for my hobbies. You may not agree with some or all aspects of my
designs, the approach that I take to them, or the theories. I have no problem
with that. Just do not ask me "what would happen if ...". Changes that
you make to the designs are for your own pleasure and at your own risk. But if
you learn something worthwhile, then please let me know. My DIY projects are not
for beginners and it may be necessary for you to buy subassemblies or a turnkey
system. Please do not ask me for individual help with your
DIY difficulties. All my designs have a Support Page. It is listed on the cover
or inside your project documentation. There is an ORION/PLUTO/LX521 Users
Group with people who can help you. I respond to every email eventually, but
you may not get the answer you want. I consider my writings in these web pages
as brief and to the point. I labor over every sentence and word and provide
little redundancy. I am not a native English speaker. I grew up in Germany. Read thoroughly and maybe more than once. I do not write for
the rank beginner, but for those who have been around the block. You may need to
study up. The links in my text are for that. I have not been standing still
since I started this website in 1999 with the idea of a brain dump of my
previous findings so they would not get lost to the audio community. In 2006,
after PLUTO, I thought I would go into a support and maintenance mode. No new
design. Stuff happened, more work to be done on radiation patterns. Also the recording and rendering
process interested me. Therefore the LX521. It brings to completion my search
for the prototype of an ideal stereo loudspeaker. It has confirmed theories and
observations of how we hear in reverberant spaces The auditory illusion is
convincing. I am satisfied. It's time to enjoy the
sublime magic of sound and space! - January, 2014
From where and in what numbers do
visitors come to this website?
Top 25 countries in a 7.5 month
period from June 2013 to January 2014 with a total of 63,734 visits (283/day):
number of visits
visits / population
For current data click on the world map
below. Then click on the continent of interest:
